No. |
Items |
Specifications |
|
1 |
Nominal Voltage |
12.8V |
|
2 |
Nominal Capacity |
86Ah |
|
3 |
Cell Inside |
LFP 86Ah |
|
4 |
Configuration |
4S1P |
|
5 |
Standard Charge Current |
16A (0.2C) |
|
6 |
Max. Charge Current |
80A (1C) |
|
7 |
Battery management System (BMS) |
Customized |
|
8 |
Continuous Discharge Current |
70A |
|
9 |
Peak Discharge Current |
140A |
|
10 |
Full Charged Voltage |
14.6V(3.65V per cell) |
|
11 |
Charge Cut-off Voltage |
15.6V (3.9V per cell) |
|
12 |
Discharge Cut-off Voltage |
8V (2.0V per cell) |
|
13 |
Net Weight |
8.8kg |
|
14 |
Dimensions |
customized |
|
15 |
Connector |
customized |
|
customized |
||
|
16 |
Operating Temperature |
Charging: 0°C ~ 45°C Discharging: -20°C ~ 55°C |
|
17 |
Storage Temperature |
(Recommended to store 20 ± 5°C for long term storage) |
|
18 |
Cycle Life |
2000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
